• Size: 5mm
• Emitted Colour : Red / Green / Blue
• Pins sequence: RED/Common Anode/Green/Blue
• Luminous Intensity: 4000/8000/5000mcd
• Forward Voltage (V) : 2.1~3.4
• View Angle: About 25 degree.

Forward

• Voltage(V)Dominant
• wavelength(mm)KLuMen(LM)Reverse
• current(uA)Power
• Angle (deg)If=20mAIf=20mAIf=20mAVr=5V

Please test to add current limiting resistor, it will be very easy to burn out the LED resistance of a few hundred to 1000ohm.

• R: wavelength 630-640nm Brightness 1000-1200mcd Voltage 1.8-2.0V
• G: wavelength 515-512nm Brightness 3000-5000mcd Voltage 3.2-3.4V
• B: wavelength 465-475nm Brightness 2000-3000mcd Voltage 3.2-3.4V
