Product Details
Wireless Power Relay To Control Electrical Supply Remotely , 110VAC~1.5KW , 230VAC~3KW , Max Load:13A , NO/NC , Freq:868.0~868.6 Mhz , Two-way Communication @ 1000M In An Open Space , IP20 , 30G ,39×33×18mm
Wireless Power Relay To Control Electrical Supply Remotely
Specifications
- Classification: Radio channel relay unit
- Device type: Wireless
- Installation method: Into wall plate
- Compatibility: Operates only with hub Ajax and ReX
- Actuating element: Relay
- Relay service life:200,000 switch-ons
- Voltage protection: For 230 V mains: max — 264 V, min — 161 V
For 110 V mains: max — 126 V, min — 77 V - Maximum load current: 13 A
- Maximum current protection: Yes (13 A)
- Maximum temperature protection: >65°C in the wall plate
- Permissible power: Resistive load at 230 V — up to 3 kW
Resistive load at 110 V — up to 1.5 kW - Electric power meter function: Available
- Energy consumption parameter check: Current, voltage, power consumption
- Alarm signal delivery time: 0.15 s
- Power supply: 110−230 V±10% 50/60 Hz
- Operation modes : Impulse (firmware version 5.54.1.0 or higher)
Bistable - Contact state (firmware version 5.54.1.0 or higher): Normally open
Normally closed - Adjustable pulse duration (firmware version 5.54.1.0 or higher): 0.5 – 255 sec
- Jeweller radio technology: Communication range with central unit — up to 1,000m in an open space
Two-way communication between devices
Operating frequencies — 868.0-868.6 MHz
Self-adjusting RF output power — up to 25 mW
Block encryption based on AES algorithm
Detector scanning period — 12−300 s - Operating temperature range: 0°С to +64°С
- Permissible humidity: Up to 75%
- Protection class of body: IP20
- Anti-sabotage: Protection against fraud
Jamming detection - Remote setting and testing: +
- Dimensions: 39 х 33 х 18 mm
- Weight: 30 g
- Certification: CE
- Warranty: Replacement and repair within 24 months of the dateof sale.
- Complete set: WallSwitch
Installation set
User’s guide
Downloads
Additional Information
| Device | Relay |
| Type | Wireless |
