Product Details
Single turn Cermet Trimmer Potentiometer, Model : 63, Size 10mm Square • PCB-X • Side Adjust • ½W @ 70°C • 1MΩ • ±10% • 1 Turn 270°
Overview
Features
Specification
Â
| Model | 63 |
| Size | 10mm Square |
| Termination | PCB-X |
| Power Rating | ½W @ 70°C |
| Resistance Value | 1MΩ |
| Tolerance | ±10% |
| Tolerance Code | K |
| Element Type | Cermet |
| No. of Turns | 1 Turn 270° |
| Adjust Style | Side Adjust |
| Mechanical Life | 200 Cycles |
