Product Details
Single turn Cermet Trimmer Potentiometer, Model : 63, Size 10mm Square • PCB-P • Top Adjust • ½W @ 70°C • 5kΩ • ±10% • 1 Turn 270°
Downloads
Additional Information
| Model | 63 |
| Device | Cermet Trimmer |
| Type | Single turn |
| Size | 10mm Square |
| Termination | PCB-P |
| Power Rating | ½W @ 70°C |
| Resistance Value | 5000Ω |
| Tolerance | ±10% |
| Tolerance Code | K |
| Element Type | Cermet |
| No. of Turns | 1 Turn 270° |
| Adjust Style | Top Adjust |
| Mechanical Life | 200 Cycles |
