Current/Voltage Measuring Module Set Current 63...630 A Voltage Measurement up to 690 V, Overall Width 145 MM, Busbar Connection
Current/Voltage Measuring Module
Specifications
- Product Name: SIMOCODE pro Digital Module (Expansion)
- Model Number: 3UF7114-1BA01-0
- Product Family: SIMOCODE pro 3UF7 Motor Management & Control Devices
- Function: Digital I/O expansion module
- Digital Inputs: 8 × digital inputs
- Digital Outputs: 4 × digital outputs (high-side)
- Relay Outputs: 2 × relay outputs
- Input Supply Voltage: AC/DC 24 V (control supply)
- Rated Control Supply Current: Approx. 50 mA (typical)
- Input Logic Levels: Defined logic HIGH/LOW per Siemens standard
- Output Current (High-side): Up to 0.5 A per output (typical, verify exact value)
- Relay Contact Rating: Standard industrial relay ratings
- Protection Class: IP20
- Operating Temperature: –25 °C to +60 °C
- Storage Temperature: –40 °C to +80 °C
- Shock Resistance: Per IEC standard (e.g., 15 g / 11 ms)
- Vibration Resistance: Per IEC standard (1–6 Hz / 15 mm; 6–500 Hz / 2 g)
- Connection Method: Screw terminals
- Mounting Type: DIN-rail mounted or snap-on
- Typical Applications: Expansion of digital I/O for SIMOCODE pro basic units
- Weight : Approx. 0.15-0.2 kg
- Width: Approx. 22.5 mm (1 modular width)
- Country of Origin: Germany or EU region
Downloads
Additional Information
| Device | Measuring Module |
| Type | Current/Voltage | Measuring | Module |
