Product Details
Sloping Console Enclosure • Polystyrene Plastic • 140 x 220 x 46 mm (With Lid) • Black
Features
- Attractively styled and ergonomically designed for use as a “hand-held” instrument enclosure
- Standard version is molded from flame retardant ABS plastic (rated UL94V-0) and is assembled with machine screws into integral brass bushings
- Recessed top for membrane display or pad
- Lap joint construction provides protection against access of dust and splashing water
- Extra deep top and ultra shallow base are specifically designed to enhance the aesthetics of the enclosure and provide the user with flexibility and assembly efficiency
- Designed to meet IP54
- Two keyhole knockouts are molded into the inside of the base to facilitate wall mounting installation.
Specifications
| Product Type | Sloping Console Enclosure |
|---|---|
| Series | 1599 |
| Body Material | Polystyrene Plastic |
| External Dimensions | 140 x 220 x 46 mm (With Lid) |
| External Length | 140 mm |
| External Width | 220 mm |
| External Height | 46 mm (With Lid) |
| Internal Dimensions | 206 x 129.5 x 39.01 mm |
| Internal Length | 206 mm |
| Internal Width | 129.5 mm |
| Internal Height | 39.01 mm |
| Colour | Black |
| IP Rating | IP54 |
| Lid Colour | Black |
| Flame Rating | UL94 V-0 |
| Number of Knockouts | 2 |
| Protection Features | Dust and Splashing Water |
