Product Details
| Circular Connector MIL-DTL-5015 Style Scw Lok SQ. Flange Panel Recpt 10 Pol #16 Cont. Male Soldr. 13A 500VAC/700VDC (MS3102A18-1P)(97-3102A-18-1P) |
CIRCULAR CONNECTOR MIL-DTL-5015 STYLE
ADDITIONAL INFORMATION
| Device | Connector |
| Type | Screw Lock | Square Flange Panel | Receptacle | 5 Poles |
| Gender | Male |
| No. of Contacts | 12 |
| No. of Pins | 5 |
| Mates With | XY3106A-18-11S |
| Locking System | Screw Lock |
| Termination | Solder |
| Electrical Rating | 23A 500VAC/700VDC |
