• Cont. power at 25°C (1) : 800VA
• Cont. power at 25°C / 40°C : 650 / 560W
• Peak power : 1500W
• Output AC voltage / frequency (adjustable) : 230VAC or 120VAC +/- 3% 50Hz or 60Hz +/- 0,1%
• Input voltage range : 9,2 - 17 / 18,4 - 34,0 / 36,8 - 62,0V
• DC low shut down (adjustable) : 9,3 / 18,6 / 37,2V
• Dynamic (load dependent) DC low shut down (fully configurable) Dynamic cut-off, see https://www.victronenergy.com/live/ve.direct:phoenix-inverters-dynamic-cutoff
• DC low restart and alarm (adjustable) : 10,9 / 21,8 / 43,6V
• Battery charged detect (adjustable) : 14,0 / 28,0 / 56,0V
• Max. efficiency : 90 / 90 / 91%
• Zero-load power : 6,5 / 7 / 9,5W
• Default zero-load power in ECO mode (default retry interval: 2,5 s, adjustable) : 1 / 1,5 / 3,0W
• ECO mode stop and start power setting : Adjustable
• Protection (2) : a - f
• Operating temperature range : -40 to +65°C (fan assisted cooling) Derate 1,25% per °C above 40°C
• Humidity (non-condensing) : max 95%

ENCLOSURE

• Material & Colour : Steel chassis and plastic cover (blue Ral 5012)
• Battery-connection : Screw terminals
• Maximum cable cross-section25 / 10 / 10mm² / AWG4 / 8 / 8
• Standard AC outlets :
  • 230V: Schuko (CEE 7/4), IEC-320 (male plug included)
  • UK (BS 1363), AU/NZ (AS/NZS 3112)
  • 120V: Nema 5-15R, GFCI
• Protection category : IP 21
• Weight :  5,5kg / 12lbs
• Dimensions (h x w x d, mm) (h x w x d, inch) : 105 x 216 x 305, 4.1 x 8.5 x 12.1 (12V model: 105 x 230 x 325)

ACCESSORIES

• Remote on-off : Yes
• Automatic transfer switch :  Filax

1. Datasheet - VICT PHOENIX INVERTER 24V/800
