Product Details
Circular Connector MIL-DTL-26482 Series 1 Style Bayonet Lock Bulkhead Jam Nut Receptacle Male 8 Pole #20 Crimp Contact 7,5A 600VAC/850VDC(KPSE07E-12-8P)(PT07SE-12-8P)(85107R128P50)
Circular Connector MIL-DTL-26482 Series 1
Specifications
|
Number of Positions
|
8
|
|
Qualification
|
MIL-DTL-26482 Series I
|
|
Shell Size - Insert
|
12-8
|
|
Mounting Type
|
Free Hanging (In-Line)
|
|
Termination
|
Solder Cup
|
|
Fastening Type
|
Bayonet Lock
|
|
Orientation
|
N (Normal)
|
|
Primary Material
|
Metal
|
|
Shell Material
|
Aluminum
|
|
Shell Finish
|
Black Zinc Cobalt
|
|
Contact Finish - Mating
|
Gold
|
|
Color
|
Black
|
|
Ingress Protection
|
Environment Resistant
|
|
Features
|
Backshell, Coupling Nut
|
|
Shielding
|
Unshielded
|
|
Current Rating (Amps)
|
7.5A
|
|
Voltage Rating
|
600VAC
|
|
Operating Temperature
|
-55°C ~ 125°C
|
|
Backshell Material, Plating
|
Aluminum, Black Zinc Cobalt
|
|
Contact Material
|
Copper Alloy
|
Additional Information
| Device | Connector |
| Type | Circular | MIL-DTL-26482 Series 1 |
