Product Details
DIN Rail Metal Case Slim Profile Switch Mode Power Supply Input: 90 ~ 264VAC/127 - 370VDC. Output 48VDC @ 2,5A. 4KVAC Isolation (NDR-120-48)
SLIM PROFILE SWITCH MODE POWER SUPPLY
OVERVIEW
LI120-20B48R2S is Mornsun AC-DC converter series featuring a cost-effective, energy efficient green power supply solution for standard DIN-rail mounting. The products offer a high level of stability and immunity to noise for industrial control equipment, machinery, and other industrial equipment in a variety of harsh environments. These light weight AC-DC converters have an extremely compact design and the standard rail installation for space saving. With good EMC performance, compliant with international UL61010, UL508, EN/BS EN 62368 standards for EMC and safety.
FEATURE
- Universal 90 - 264VAC or 127 - 370VDC Input voltage
- Accepts AC or DC input (dual-use of same terminal)
- Operating ambient temperature range: -20℃ to +60℃
- High I/O isolation test voltage up to 4000VAC
- Low ripple & noise
- Output short circuit, over-current, over-voltage,
over-temperature protection - DIN rail TS-35/7.5 or 15 mountable
- Ultra slim design: suitable for small chassis and narrow
space installation - Safety according to UL508
SPECIFICATIONS
| Type | DIN Rail Single Output |
| Output Power | 120W |
| Series | LI120-20B |
| Part Number | LI120-20B48R2S |
| Mount | DIN-Rail |
| IP Level | Non-Waterproof |
| Output Voltage | 48V |
| Output Current | 2,5A |
ADDITIONAL INFORMATION
| Group | Power Adaptors |
| Device | Power Supply |
| Type | Slim Profile | Switch Mode |
| Input Voltage | 90 ~ 264VAC/127 - 370VDC |
| Output | 48VDC @ 2,5A |
| Size | W-36mm x H-125mm x D-100mm |
