Encapsulated PCB Mount Switch Mode Power Supply Input: 85 ~ 305VAC/100 - 430VDC. Output 24VDC @ 830mA. (IRM-20-24)
PCB MOUNT SWITCH MODE POWER SUPPLY
FEATURE
- Ultra-wide 85 - 305VAC and 100 - 430VDC input voltage
range
- Operating ambient temperature range: -40℃ to +85℃
- Up to 87% efficiency
- No-load power consumption 0.1W
- 5000m altitude application
- OVC Ⅲ (meet EN61558-1)
- Plastic case meets UL94V-0 flammability
- EMI performance meets CISPR32/EN55032 CLASS B, EN55014
ADDITIONAL INFORMATION
| Device |
Power Supply |
| Type |
PCB Mount | Switch Mode |
| Input Voltage |
85 ~ 305VAC/100 - 430VDC |
| Output |
24VDC |
| Output Current |
830mA |
| Size |
52.40 x 27.20 x 24.00 mm |
