Encapsulated Surface Mount Switch Mode Power Supply Input: 90 ~ 528VAC/100 - 745VDC. Output 5VDC @ 2A. 4KVAC Isolation
SURFACE MOUNT SWITCH MODE POWER SUPPLY
FEATURE
- Ultra wide input voltage range: 90 - 528VAC/100 - 745VDC
- Regulated output, Low ripple & noise
- Operating temperature range: -40℃ to +70℃
- Output short circuit, over-current, over–voltage protection
- Isolation voltage: 4KVAC
- EFT /Surge: ±4KV Perf. Criteria B
- EN62368 approval
ADDITIONAL INFORMATION
| Device |
Power Supply |
| Type |
Surface Mount | Switch Mode |
| Input Voltage |
90 ~ 528VAC/100 - 745VDC |
| Output |
5VDC |
| Output Current |
2A |
| Size |
96.10 x 54.00 x 38.50 mm |
