Product Details
Encapsulated PCB Mount Switch Mode Power Supply Input: 85 ~ 305VAC/100 - 430VDC. Output 24VDC @ 410mA.
PCB Mount Switch Mode Power Supply
Feature
- Ultra-wide 85 - 305VAC and 100 - 430VDC input voltage range
- Operating ambient temperature range: -40℃ to +85℃
- Up to 85% efficiency
- No-load power consumption < 0.1W
- 5000m altitude application
- EMI performance meets CISPR32/EN55032 CLASS B, EN55014
- Design to meet IEC/EN60601-1/ANSI/AAMI ES60601-1
standards (2xMOPP)
Downloads
Additional Information
| Device | Power Supply |
| Type | PCB Mount | Switch Mode |
| Input Voltage | 85 ~ 305VAC/100 - 430VDC |
| Output | 24VDC @ 410mA |
| Size | 40.00 x 25.40 x 21.00 mm |
