Product Details
High Power Surface Flange Mounted Relay With 6,3mm Fast-On Terminals Form 2C (2c/o) 240VAC Coil 8060 Ohm 30A/250VAC/30VDC
High Power Surface Flange Mounted Relay
Additional Information
| Device | Relay |
| Type | High Power | Surface Flange | Mounted |
| Highlights | Size 45 x 36 x 48mm High inc. Terminals. 38mm Mounting Centres |
| Contact Form | Form 2C (2c/o) |
| Coil Rated Voltage | 240V |
| AC/DC Voltage | AC |
| Max. Switching Current | 30A |
| Electrical Rating | 250VAC/30VDC |
| Coil Resistance | 8060Ω |
