Smart Function

•  All channels support Motion Detection 2.0
•  2-ch video analysis for human and vehicle recognition to reduce false alarm
•  1-ch facial recognition for video stream, or 4-ch facial recognition for face picture
•  Smart search for the selected area in the video, and smart playback to improve the playback efficiency

Professional and Reliability

• H.265+ compression effectively reduces the storage space by up to 75%
•  Adopt stream over TLS encryption technology which provides more secure stream transmission service

HD Video Output

• Provide independent HDMI and VGA outputs
•  HDMI video output at up to 4K resolution

Storage and Playback

•  Up to 2 SATA interfaces for HDD connection (up to 10 TB capacity per HDD)
• 8-ch synchronous playback

Network & Ethernet Access

• 8 independent PoE network interfaces
• 1 self-adaptive 10/100/1000 Mbps Ethernet interface
•  Hik-Connect for easy network management

•  Up to 8-ch IP camera inputs, plug & play with 8 power-over-Ethernet (PoE) interfaces
•  H.265+/H.265/H.264+/H.264 video formats
•  Up to 2-ch@12 MP or 3-ch@8 MP or 6-ch@4 MP or 12-ch@1080p decoding capacity
•  Up to 80 Mbps incoming bandwidth
•  Adopt Hikvision Acusense technology to minimize manual effortand security costs

Intelligent Analytics

• AI by Device: Facial recognition, perimeter protection, motion detection 2.0
• AI by Camera: Facial recognition, perimeter protection, throwing objects from building, motion detection2.0, ANPR, VCA

Facial Recognition

• Facial Detection and Analytics: Face picture comparison, human face capture, face picture search
• Face Picture Library: Up to 16 face picture libraries, with up to 20,000 face pictures in total (each picture ≤ 4 MB, total capacity ≤ 1 GB)
• Facial Detection and Analytics Performance : 1-ch, 8 MP
• Face Picture Comparison: 4-ch

Motion Detection 2.0

• By Device:All channels, 4 MP (when enhanced SVC mode is enabled, up to 8 MP) video analysis for human and vehicle recognition to reduce false alarm
• By Camera: All channels

Perimeter Protection

• By Device: 2-ch, 4 MP (HD network camera, H.264/H.265) video analysis for human and vehicle recognition to reduce false alarm
• By Camera: All channels

Video and Audio

• IP Video Input: 8-ch
• Incoming Bandwidth: 80 Mbps
• Outgoing Bandwidth: 160 Mbps
• HDMI Output: 1-ch, 4K (3840 × 2160)/30 Hz, 2K (2560 × 1440)/60 Hz, 1920 × 1080/60 Hz, 1600 ×
                       1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz
• VGA Output :  1-ch, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz
• Video Output Mode:  HDMI/VGA independent output
• CVBS Output: N/A
• Audio Outpu: 1-ch, RCA (2.0 Vp-p, 1 KΩ, using the audio input)
• Two-Way Audio: 1-ch, RCA (Linear, 1 KΩ)

Decoding

• Decoding Format : H.265/H.265+/H.264+/H.264
• Recording Resolution : 12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
• Synchronous playback : 8-ch
• Decoding Capability: AI on: 1-ch@12 MP (30 fps)/2-ch@8 MP (30 fps)/4-ch@4 MP (30 fps)/8-ch@1080p (30 fps)

                              AI off: 2-ch@12 MP (30 fps)/3-ch@8 MP (30 fps)/6-ch@4 MP (30 fps)/12-ch@1080p (30fps)

• Stream Type: Video, Video & Audio
• Audio Compression: G.711ulaw/G.711alaw/G.722/G.726/AAC

Network

• Remote Connection: 128
• API ONVIF :(profile S/G); SDK; ISAPI
• Compatible Browser: IE11, Chrome V57, Firefox V52, Safari V12, Edge V89, or above version
• Network Protocol: TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnPTM, HTTP, HTTPS
• Network Interface: 1 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface

PoE

• Interface: 8, RJ-45 10/100 Mbps self-adaptive Ethernet interface
• Power: ≤ 80 W
• Standard: IEEE 802.3af/at

Auxiliary Interface

• SATA: 2 SATA interfaces
• Capacity: Up to 10 TB capacity for each HDD
• USB Interface: Front panel: 1 × USB 2.0; Rear panel: 1 × USB 2.0
• Alarm In/Out: 4/1

General

• GUI Language :English, Russian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French,
                         Polish, Dutch, Portuguese, Spanish, Romanian, Turkish, Japanese, Danish, Swedish
                         Language, Norwegian, Finnish, Korean, Traditional Chinese, Thai, Estonian, Vietnamese,
                         Croatian, Slovenian, Serbian, Latvian, Lithuanian, Uzbek, Kazakh, Arabic, Ukrainian,
                         Kyrgyz , Brazilian Portuguese, Indonesian

• Power Supply: 48 VDC, 2.5 A
• Consumption: ≤ 15 W (without HDD, and PoE off)
• Working Temperature: -10 °C to 55 °C (14 °F to 131 °F)
• Working Humidity: 10% to 90%
• Dimension (W × D × H): 385 mm × 315 mm × 52 mm (15.2"× 12.4" × 2.0")
• Weight: ≤ 3 kg (without HDD, 6.6 lb.)

Certification

• FCC: Part 15 Subpart B, ANSI C63.4-2014
• CE: EN 55032: 2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4, EN 55035: 2017
• Obtained Certification: CE, FCC, IC, CB, KC, UL, Rohs, Reach, WEEE, RCM, UKCA, LOA, BIS
