Product Details
High Power Horizontal PCB Mounted Sealed Relay Form 1A (1n/o) with 6,3mm Recessed Fast-on Terminals 24VDC 660 Ohm Coil 40A- 240VAC/28VDC (40A @ 277VAC/28VDC Max.) - Class F Insulation
Miniature High Power Relay
Additional Information
| Device | Relay |
| Type | Miniature | High Power | PCB |
| Contact Form | Form 1A (1n/o) |
| Termination | PCB |
| Coil Rated Voltage | 24V |
| AC/DC Voltage | DC |
| Electrical Rating | 40A- 240VAC/28VDC (40A @ 277VAC/28VDC Max.) |
| Coil Resistance | 660Ω |
