Product Details
| Cordset Shielded M12 D-Code Profinet Type C/EtherCAT Male Straight 4 Pole - Open Ended 5M PUR Cable IP67. |
- Shielded M12 Ethernet connection cable
- Cat.5e, 4-pole, D-coded (IEC 61076-2-101)
- Side 1: M12-plug, straight
- Side 2: free line end
- Extrusion-coated cable on M12 connector
- 2x2xAWG22/7, tinned with plastic foil
- Inner sheath FRNC, aluminum-coated plastic foil
- Overall shield: tinned copper braid, approx. 85% covered
- Profinet (WS-GE-BL-OR) wiring
- Green cable, PUR
