HQ-002.1-F - Heavy Duty Power Connectors HAN Q 2/0-F HV 2 5-6 MM2
HQ-002.1-F - Heavy Duty Power Connectors HAN Q 2/0-F HV 2 5-6 MM2
Couldn't load pickup availability
The Han Q series female insert is a robust component designed for heavy-duty power connector applications.
This specific insert features 12 poles (2 power contacts plus PE) with a screw termination style, capable of handling a current rating of 40 A and a voltage rating of 830 V. It is designed to fit within a size 3A housing/hood.
Constructed from grey polycarbonate (PC) housing material with silver-plated copper alloy contacts, this insert offers reliable performance within a wide operating temperature range of -40 °C to +125 °C. It accommodates wire gauges from 14 AWG to 10 AWG and holds a V-0 flammability rating. Part of the broader category of power connectors and the subcategory of power connectors, this female insert carries the Tradename Han
Article No. 130 002 021 0001
SPECIFICATIONS
| Inserts | |
| Number of contacts | 2+PE |
| Electrical data acc. to EN 61 984 | |
| ---Rated current | 40A |
| ---Rated voltage | 400V |
| ---Rated impulse voltage | 6kV |
| ---Pollution degree | 3 |
| Rated voltage acc. to UL | 400V |
| Insulation resistance | ≥1010Ω |
| Material | polycarbonate |
| Limiting temperatures | -40℃...+125℃ |
| Flammability acc. to UL 94 | V0 |
| Mechanical working life(mating cycles) | ≥500 |
| Contacts | |
| Material | copper alloy |
| Surface | hard-silver plated |
| Contact resistance | ≤1mΩ |
| Axial screw termination | |
| ---mm2 | 2.5-10mm2 |
| ---AWG | 14-8 |
| Tightening torque | 1.8Nm |
| Stripping length |
8+1mm |
